 extreme resistance to abrasion made of alloyed steel and chilled cast iron.
prevents from a noise and vibration with the precise helical gear.
has a effective turnover ratio, 1:3:9 or 1:4:12
available cooling and heating
reduce a vibration and rocking as uniformity and accurate manufacture of a part of machine.
be easy to overhaul
be easy to adjust the R.P.M 0~300
be able to control the R.P.M | |
| |
| |
 |
| |
| paint ink cosmetics medicine food urethane epoxy | |
| |
| |
| Model |
Roller (D" X L") |
Motor(HP) |
R.P.M |
Dimension
(m/m X m/m X m/m) |
|
| HSTRM- 16" |
16" X 42" |
25 |
180 X 230 |
1980 X 1860 X 1330 |
| HSTRM- 14" |
14" X 32" |
15 |
180 X 230 |
1720 X 1630 X 1180 |
| HSTRM- 12" |
12" X 27" |
10 |
180 X 250 |
1486 X 1430 X 1020 |
| HSTRM- 9" |
9" X 20" |
5 |
180 X 250 |
1130 X 1080 X 960 |
| HSTRM- 6 ½" |
6 ½" X 17" |
3 |
180 X 280 |
990 X 850 X 860 |
| HSTRM- 5 ½" |
5 ½" X 14" |
2 |
180 X 280 |
620 X 580 X 700 |
| HSTRM- 4 ½" |
4 ½" X 12" |
2 |
180 X 280 |
848 X 838 X 1050 | | |
| |
| |
 |
* Details can be found by clicking the picture. |
| |
 |
| 12inch Three Roll-Mill | |
|
 |
| 12inch Three Roll-Mill | |
|
 |
| 12inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | |
|
 |
| 14inch Three Roll-Mill | | | |
